6010 PRO Motor

The 6010 PRO motor is a high-performance brushless motor designed for medium to large UAV applications. This documentation covers the 160 KV variant with detailed specifications and test data.

Key Features:

• High thrust up to 6,778g for heavy-lift UAVs
• Lightweight design (240g) for efficient flight
• Compatible with 20"–23" propellers
• Durable dual 626-2Z sealed bearings for long operational life
• High power density (up to 7.13 W/g maximum)
• Optimized for endurance and high-speed applications

160 KV

160 KV - Specifications

Motor Specifications:

• KV Rating: 160 RPM/V
• Kt (Motor Torque Constant): 0.029 Nm/A @ 4250 RPM
• Weight: 240g ± 10g
• Max Thrust: 6,778g (with TM 22×6.6 CF_FX prop)
• Voltage Range: 44V – 50V (12S LiPo)
• Io (No Load Current @ 48V): 1.2A
• Max Continuous Current: 20A (180s)
• Max Continuous Power: 910W (180s)
• Power Density: 3.79 W/g (Rated), 7.13 W/g (Maximum)
• Motor Diameter: Ø 68.8 mm
• Motor Length: 32 mm
• Shaft Diameter: Ø 4.8 mm
• Stator Poles: 24S
• Magnetic Poles: 28P
• Bearings: Dual 626-2Z Sealed
• Inductance per phase (Winding Inductance): 0.102 (≈0.03) mH
• Resistance per phase (Rph): 0.138 (≈0.03) Ω
• Motor Mount Pattern @ 90°: 12 × M3 @ PCD Ø 12 mm, Ø 18 mm, Ø 20 mm, depth: 8 mm
• Compatible Propeller Size: 20" to 23"
• Propeller Mount Pattern: 4 × M4 @ PCD Ø 30 mm, depth: 8 mm

Test Data - 160 KV

TM 2009 CFRP_FP Propeller

Test Conditions:

• ESC: TM 60A 12S
• Battery: 2 × TB – 22000 mAh 12S
• Test Date: 16-04-2025
• Environmental Temp: 28°C
• Humidity: 58%
• Cross-winds: Moderate

PWM	Throttle %	Voltage (V)	Current (A)	RPM	Thrust (g)	Torque (N·m)	Power (W)	Efficiency (g/W)	Temp (°C)
1300	30	50.1	1.0	2200	640	0.19	48.7	13.1	43°C (@70% 10 min Constant)
1400	40	50.0	2.3	2946	1164	0.33	114.2	10.2	43°C (@70% 10 min Constant)
1500	50	49.8	4.4	3718	1827	0.48	218.5	8.4	43°C (@70% 10 min Constant)
1600	60	49.6	6.9	4322	2539	0.65	340.4	7.5	43°C (@70% 10 min Constant)
1700	70	49.4	10.2	4938	3370	0.83	505.4	6.7	43°C (@70% 10 min Constant)
1800	80	49.2	14.1	5515	4081	1.03	692.8	5.9	48°C (Maximum)
1900	90	48.8	19.0	6090	4956	1.22	928.6	5.3	48°C (Maximum)
1950	95	48.6	22.8	6415	5618	1.38	1107.2	5.1	48°C (Maximum)
2000	100	48.6	22.5	6423	5605	1.35	1095.7	5.1	48°C (Maximum)

KDE 21 × 7.3 CF_FP Propeller

Test Conditions:

• ESC: TM FLAME 60A 12S
• Battery: 2 × TB – 22000 mAh 12S
• Test Date: 21-11-2024
• Environmental Temp: 28°C
• Humidity: 43%
• Cross-winds: Mild

PWM	Throttle %	Voltage (V)	Current (A)	RPM	Thrust (g)	Torque (N·m)	Power (W)	Efficiency (g/W)	Temp (°C)
1300	30	49.4	1.5	2148	830	0.24	74.1	11.2	56°C (@70% 10 min Constant)
1400	40	49.3	3.3	2857	1555	0.43	162.7	9.6	56°C (@70% 10 min Constant)
1500	50	49.1	6.5	3550	2499	0.67	319.2	7.8	56°C (@70% 10 min Constant)
1600	60	48.8	10.4	4128	3429	0.91	507.5	6.8	56°C (@70% 10 min Constant)
1700	70	48.5	14.9	4607	4253	1.15	722.7	5.9	56°C (@70% 10 min Constant)
1800	80	48.1	21.3	5085	5219	1.41	1024.5	5.1	60°C (Maximum)
1900	90	47.7	29.3	5488	6130	1.63	1397.6	4.4	60°C (Maximum)
1950	95	47.4	34.6	5696	6591	1.75	1640.0	4.0	60°C (Maximum)
2000	100	47.4	34.3	5698	6536	1.74	1625.8	4.0	60°C (Maximum)

TM 22 × 6.6 CF_FX Propeller

Test Conditions:

• ESC: HW 80A 12S
• Battery: 2 × TB – 22000 mAh 12S
• Test Date: 21-11-2024
• Environmental Temp: 28°C
• Humidity: 43%
• Cross-winds: Mild

PWM	Throttle %	Voltage (V)	Current (A)	RPM	Thrust (g)	Torque (N·m)	Power (W)	Efficiency (g/W)	Temp (°C)
1300	30	49.4	0.9	1862	621	0.17	44.5	14.0	55°C (@70% 10 min Constant)
1400	40	49.3	2.3	2557	1217	0.31	113.4	10.7	55°C (@70% 10 min Constant)
1500	50	49.1	5.1	3391	2192	0.56	250.4	8.8	55°C (@70% 10 min Constant)
1600	60	48.9	8.9	4094	3159	0.81	435.2	7.3	55°C (@70% 10 min Constant)
1700	70	48.5	14.0	4670	4264	1.08	679.0	6.3	55°C (@70% 10 min Constant)
1800	80	48.1	20.4	5217	5406	1.37	981.2	5.5	59°C (Maximum)
1900	90	47.6	28.4	5733	6416	1.63	1351.8	4.7	59°C (Maximum)
1950	95	47.5	30.7	5822	6704	1.70	1458.3	4.6	59°C (Maximum)
2000	100	47.5	31.4	5785	6778	1.75	1491.5	4.5	59°C (Maximum)

VT 2308 CFRP_FP Propeller

Test Conditions:

• ESC: HW 80A 12S
• Battery: 2 × TB – 22000 mAh 12S
• Test Date: 21-11-2024
• Environmental Temp: 30°C
• Humidity: 39%
• Cross-winds: Mild

PWM	Throttle %	Voltage (V)	Current (A)	RPM	Thrust (g)	Torque (N·m)	Power (W)	Efficiency (g/W)	Temp (°C)
1300	30	49.2	1.4	1781	796	0.27	68.9	11.6	74°C (@70% 10 min Constant)
1400	40	49.0	3.1	2360	1477	0.46	151.9	9.7	74°C (@70% 10 min Constant)
1500	50	48.8	7.6	3182	2748	0.85	370.9	7.4	74°C (@70% 10 min Constant)
1600	60	48.2	12.3	3695	3704	1.11	592.9	6.2	74°C (@70% 10 min Constant)
1700	70	47.9	19.0	4250	4777	1.41	910.1	5.2	74°C (@70% 10 min Constant)
1800	80	47.3	28.2	4643	5685	1.68	1333.9	4.3	80°C (Maximum)
1900	90	46.7	37.5	4891	6113	1.82	1751.3	3.5	80°C (Maximum)
1950	95	46.6	38.2	4966	6198	1.84	1780.1	3.5	80°C (Maximum)
2000	100	46.7	36.7	4983	6176	1.84	1713.9	3.6	80°C (Maximum)

Performance Summary:

• Best Efficiency: TM 22×6.6 CF_FX @ 30% throttle (14.0 g/W, 621g thrust)
• Maximum Thrust: TM 22×6.6 CF_FX @ 100% throttle (6,778g thrust, 4.5 g/W)
• Balanced Performance: TM 2009 CFRP_FP @ 70% throttle (3,370g thrust, 6.7 g/W)
• Operating Temperature: 43-80°C depending on load and propeller
• Recommended Continuous: 70% throttle max for sustained flight

Recommended Applications - 160 KV

• Large commercial UAVs
• Heavy payload applications
• Long-endurance missions
• Professional cinematography

Common Resources

2D CAD Drawing

The 2D CAD drawing provides detailed dimensions and mounting specifications for the 6010 PRO motor.

Download 2D CAD Drawing

Drawing Specifications:

• Motor Mount Pattern @ 90°: 12 × M3 @ PCD Ø 35 mm, depth: 8 mm
• Propeller Mount Pattern: 4 × M4 @ PCD Ø 30 mm, depth: 8 mm
• Motor Diameter: Ø 61.8 mm
• Motor Length: 30.8 mm
• Stick Out Shaft Diameter: Ø 6.35 mm

Note: All dimensions in millimeters (mm). Specifications and drawings may be revised without notice.

Recommended ESC & Propeller

Compatible ESCs

Recommended Configurations:

ESC Rating	Application	Features
60A	General purpose	Standard BLHeli_32
80A	High performance	Advanced telemetry
100A+	Heavy lift	Enhanced cooling, FOC

ESC Requirements:

• Continuous rating: 60A minimum (80A recommended)
• Voltage support: 12S (44-50V) capable
• Protocol: DShot600 or higher recommended
• Features: Active braking, telemetry support, FOC capability

For detailed ESC specifications and compatibility, see ESC Overview.

Compatible Propellers

Tested Propeller Configurations:

Propeller Size	Pitch	Application	Performance
TM 2009	Medium	Efficiency	Very Good
TM 22×6.6	High	Maximum thrust	Excellent
VT 2308	High	Heavy lift	Very Good

Propeller Selection Guidelines:

• Start with TM 22×6.6 for best overall performance
• Use TM 2009 for efficiency-focused applications
• Use VT 2308 for heavy lift applications
• Always balance propellers before installation
• Carbon fiber recommended for high performance

For more propeller options, see Propeller Overview.

System Integration

Complete System Recommendations:

1. Efficiency Build (Long flight time)

   • Motor: 6010 PRO 160KV
   • Propeller: TM 22×6.6 CF_FX
   • ESC: 60A FOC
   • Battery: 12S 10000mAh
   • Expected Performance: 3,429g thrust, 300+ seconds runtime

2. Balanced Build (General purpose)

   • Motor: 6010 PRO 160KV
   • Propeller: TM 2009 CFRP_FP
   • ESC: 80A FOC
   • Battery: 12S 8000mAh
   • Expected Performance: 4,956g thrust, 240-300 seconds runtime

3. Performance Build (Maximum thrust)

   • Motor: 6010 PRO 160KV
   • Propeller: TM 22×6.6 CF_FX
   • ESC: 100A FOC
   • Battery: 12S 6000mAh
   • Expected Performance: 6,778g thrust, 180 seconds runtime

Maintenance and Inspection

Pre-Flight Checks

Before every flight:

• Visual inspection for physical damage
• Propeller balance and condition check
• Mounting bolt security verification
• Wire routing inspection (no contact with moving parts)
• Brief spin test (listen for unusual sounds)

Periodic Maintenance Schedule

Every 10 Flight Hours:

• Re-torque mounting bolts to specification
• Inspect threadlocker integrity
• Check bearing smoothness (manual rotation)
• Clean motor exterior with compressed air
• Inspect propeller for wear or damage

Every 50 Flight Hours:

• Detailed bearing inspection
• Shaft runout measurement
• Electrical connection integrity check
• Replace propeller if worn
• Document maintenance in flight log

Signs Requiring Immediate Inspection:

• Unusual vibration during operation
• Increased motor temperature (>85°C)
• Grinding or scraping sounds
• Reduced thrust output
• Propeller wobble

Bearing Replacement

Bearing Specifications:

• Type: Dual 626-2Z Sealed
• Service Interval: 100-150 flight hours (typical)
• Replacement Procedure: Contact technical support or refer to motor maintenance procedures

Signs of Bearing Wear:

• Grinding or rattling sounds
• Increased vibration
• Shaft play or wobble
• Difficulty rotating by hand
• Increased operating temperature

Comparison with Similar Motors

PRO Series Comparison

PRO Series Comparison

Feature	6010 PRO	4015 PRO
Weight	240 g	238 g
Max Thrust	6,778g (160KV)	4,334g (340KV)
Voltage	48V (12S)	24V (6S)
Prop Size	20-23"	16-18"
Application	Large UAVs	Medium-Large UAVs
Mounting	M3/M4 bolts	M3 bolts

SL Series Alternatives

Feature	6010 PRO	8008 SL	8015 SL
Weight	240 g	210 g	420 g
Max Thrust	6,778g	~10 kg	13.5 kg
Voltage	48V (12S)	48V (12S)	48V (12S)
Prop Size	20-23"	28-30"	up to 30"
Build	Standard	Lightweight	Heavy-duty

Selection Guide:

• 6010 PRO: Best for large UAVs requiring high thrust and efficiency
• 4015 PRO: Lower voltage option for medium-large UAVs
• 8008/8015 SL: Step up for very large commercial UAVs

See Motor Overview for complete specifications.

Safety Notes

⚠️ Important Safety Information

Operational Safety:

• Never run motor without propeller attached (causes unbalanced load)
• Ensure proper cooling during extended operation
• Monitor motor temperature - do not exceed 85°C for sustained periods
• Inspect motor bearings regularly for wear
• Replace damaged propellers immediately

Electrical Safety:

• Verify correct ESC wiring before first power-up
• Use only 12S LiPo batteries (44-50V range)
• Do not exceed maximum continuous current (20A @ 180s)
• Ensure proper battery discharge rates (C-rating)
• Use ESCs rated for 12S operation

Installation Safety:

• Follow torque specifications exactly
• Never exceed maximum bolt depth (8mm for both motor mount and propeller mount)
• Verify rotation direction before propeller installation
• Maintain minimum 15mm clearance to frame
• Use proper size mounting hardware (M3 for motor, M4 for propeller)

Emergency Procedures:

• If motor overheats (>85°C), land immediately
• If unusual vibration occurs, stop operation
• If motor makes grinding sounds, inspect bearings
• Always have emergency landing plan

Technical Support & Resources

Contact Information

• Technical Support: support@vectortechnics.com
• Phone Support: +918977744819 (Mon-Fri, 9AM-5PM IST)

Related Documentation

• Motor Installation Guide
• ESC Configuration Guide
• Propeller Selection Guide
• Motor Overview
• PRO Series

---

Next Steps:

1. Review Installation Guide for mounting procedures
2. Select compatible ESC from tested configurations
3. Choose optimal propeller based on application
4. Review Motor Overview for system integration

Document Information:

• Revision: 1.0
• Last Updated: February 2026
• Product Code: VT-6010PRO-160KV
• Document ID: VT-DOC-6010PRO-01

Note: Specifications and drawings may be revised without notice. Vector Technics assumes no liability for reliance on unverified data. All dimensions in millimeters (mm).
